PRODUCT OVERVIEW
LIFTOAL SolidGrip SuperBooster�, is an ergonomically designed StableArm Manipulator, contributes to your healthier workplaces and more efficient productions.
With the characteristics of rigid structure, smooth movement and adaptive balance floating state of any weight, it makes material lifting and assembling easy and fast, especially for the precise positioning of the workpiece.�
SolidGrip SuperBooster, is a Manipulator with extremely high load capacity, able to handle loads up to 650kg, and reach radius up to 3 meters, which makes it an ideal solution in workplaces where heavy loads are handled.�
Equipped with load indication, mis-operation protection, air failure protection and other safety devices, they assure the operator with the utmost safety.�
TECHNICAL DATA
CM – Column Mounted�
| Type | PBF-SB-CM350 | PBF-SB-CM400 | PBF-SB-CM450 | PBF-SB-CM500 | PBF-SB-CM550 | PBF-SB-CM600 | PBF-SB-CM650 |
|---|---|---|---|---|---|---|---|
| Max. load(kg) | 350 | 400 | 450 | 500 | 550 | 600 | 650 |
| Max radius R1 (mm) | 3000 | 3000 | 3000 | 2500 | 2500 | 2000 | 2000 |
| Min radius R2 (mm) | 1000 | 1000 | 1000 | 850 | 850 | 700 | 700 |
| Overall Height H (mm) | 5000 | 5000 | 5000 | 4600 | 4600 | 4300 | 4300 |
| Pedestal W (mm) | 1000*1000 | 1000*1000 | 1000*1000 | 1000*1000 | 1000*1000 | 1000*1000 | 1000*1000 |
Note: The data could be adjusted according to the actual situation
